IMPACT Silverback GR Series Suction Pump
Brands
IMPACTIndustry Standard
Industrial StandardSilverback GR Series pumps have been created specifically to meet the challenges of the suction side of the frac blender. They are designed to stand up to continuous, high-volume pumping of fluids in a variety of clean and mild abrasive applications.
| Size | 8”x6”x16” |
| Casing | Carbon Steel |
| Impeller | Duplex Stainless Steel |
| Expeller | Duplex Stainless Steel |
| Impeller Shaft | 17-4 Stainless Steel |
| Replaceable Wear Rings | Hardened Stainless Steel |
| Bearing Housing | Carbon Steel |
| Radial Bearing | Cylindrical Roller Bearing |
| Thrust Bearing | Duplex Angular Contact Bearings |
| Bearing Lubrication | Grease |
| Gasket | Modified PTFE (Acid Rated) |
| Weight | 455 kg (1000 lbs) |
| Silverback GR Series Brochure | Download |
